Team Rocket F1-EVO Construction  Home Page                 Page Last Modified: Friday, 05-Sep-2008 08:24:36 EDT


Click here for my Flight Log!!!


A little YouTube video of a departure from Brazil-Clay County airport 5/08:


Rudy Siegel shot and uploaded a short video of my departure at Moraine Airpark.







Click here to go to my flying "blog" page.



First Cross Country




On The Ground at BMG


Jim Winings in Formation Near 2R2


Dec 14, 2007
. First Flight!   Finally the sun came out, the air cleared somewhat and the airport began to dry out. Oddly enough, about 5 of my flying buddies figured out that I would try to go to the airport and fly today, and they showed up just at the right time.  It was nice to have a gallery of friends, well wishers, ground crew and photographers. You meet the nicest people at airports!



I pulled my Rocket out and climbed in. Strapped down and started up. It was a relatively balmy 60 degrees in my hangar with the sun on it even though it was about 30 outside, so my oil was somewhat warm before I even started. Waited for all the instruments (the EFIS) to show green and taxied out.


"Oh, you gotta get you wunna THESE!"


Here's some YouTube vids of my first flight:

First Take Off     Not much to look at, but glad to have the documentation.
First and Second Time Around the Patch    T-N-G, 190 knot pass!
First Landing    sweetness!
Taxiing Back to My Hangar after First Flight    Yeah, baby!
Second Take Off    500 feet is all it took. I can do better. A LOT better!


" Airworthy!! "
Dec 1, 2007:  I now am the proud owner of an airplane!  My F1-EVO Rocket is no longer a kit, but a bonafide airplane! Woohoo! Inspection with FSDO went smooth as silk, and was actually quite a pleasant time.  I learned a few things, did lots of paperwork and about froze my butt off because my space heater quit near the end. Well, it was worth it to get that special pink slip and my repairman's certificate.

The plane sits in the hangar. Ready for first flight, except that I need to re-install the engine cowls (from the inspection).


My AIRPLANE:
Click this pic to go to a current project page!


CLEAR!!

Engine START!  WOOHOO!!  The engine runs beautifully, started right up on the first try. Thanks to Mattituck for such a fine product.



Now THAT'S what I'M talking about!  11/02/07 was a big day. Hooked up jacks to tap into the avionics stack and went for a drive. Talked to the tower on the strut antenna. Taxied over to the big taxiway (wider and longer than most runways) and  dropped the flaps. Prop full forward, a little gas, forward on the stick. About 50 feet later the tail gently elevated. The view out the front was SPECTACULAR!





This plane is a PUSSYCAT on the mains with the tail up. Wow, what a treat! Glad to say that my mains seem beautifully aligned and the plane tracks true. All systems are GO!!!!!!!  Click this link if you want to watch a 14 meg mpeg of a taxi run. Warning: it's SLOW to load.


F1 BOSS werdz of wizdumb: " Think TRACTOR, not Space Shuttle..."

The digest version of my building progress:

I gathered the certification paperwork for the feds. The Indianapolis FSDO is one of the few that still does certification inspections. Once I had my paperwork ready, I forwarded that to the safety supervisor, and he in turn assigned an inspector. One thing that was not in the check list, and which I neglected to send with my packet, was an application for my repairman certificate. That application is supposed to be sent in with the airworthiness application. The inspector made an appointment with me and gave me a list of things to have ready. He came, went over the airframe, and went through the paperwork, and signed off my airplane. And I got my repairman's certificate!

With the help of some fellow hangar rats, I loaded up the plane with all the parts and weighed it. I calculated the base Weight & Balance after computing the Empty Weight.  I copied another pilot's website and modified a page to online W&B calculations for an F1-EVO. I made a copy of the W&B to be in the POH and a copy needs to always be in the aircraft. My Rocket weighed in unpainted at 1314, with 62 pounds on the tail.

My old aviation insurance agency tried like the dickens to get someone to give them a quote for Rocket coverage on my behalf. As you might expect, getting Rocket coverage is difficult and expensive. Only three carriers are known to provide Rocket (Harmon, F1, whatever) coverage.

The Garmin/Garmin AT stack is installed in the panel, with respective trays, and the wiring harness completely installed. The TruTrak autopilot contoller came direct from the mfctr and is installed and working. 5 antennas area installed and ready. The  Horizon I dual screen, single AHRS  EFIS with EIS engine monitor is installed in the instrument panel, and the AHRS installed and calibrated. The EIS unit is mounted and the power wires connected. The magnetometer is mounted in the turtledeck and the wires are connected. Works GREAT!  I upgraded the memory in each EFIS DU to 1 gigabyte, and uploaded terrain data for all of North America and all current software.

My Mattituck TMX-IO-540 engine runs like a champ.  Purrs like the proverbial lion. HAH!   Screw YOU Mike Moore you cheating bastard. When are you going to pay me my money back, you crook?! The Engine Cowl has Skybolt C-loks installed and all the screws and nutplates are installed. The air filter is in the scoop and the scoop screwed to the lower cowl. My MT Propeller and governor are installed, the prop is torqued and safetied, and the spinner is installed. The engine hard baffles are assembled and the soft baffles are riveted to the hard baffles. I've installed the Airflow Performance FM200 assy on the bottom of the sump. I've installed the Vetterman exhaust and the Rick Robbins heat muffs are installed. The fuel hoses are in position and the control cables installed onto their respective brackets, adjusted and cotter pinned. Spark plug wires are trimmed, crimped and attached. The wires for the Plama III coils are trimmed and terminated, and the ground shield soldered. The EGT and CHT wires are installed, terminated and connected. All sensor wires and hoses are installed. I've hung the oil cooler and the cooler ducts and hoses are finished. I've run engine control cables, and  the fuel and MAP hoses. The alternator and starter are wired and good to go. I went back and modified the mechanical fuel pump drain port to drain out the bottom and installed a drain hose.

I have both  EVO tapered wings installed.  The flap fairings (gap seals) are finished. The bracket assys for the aileron push tube mechanism, the push tubes, caps and rod ends are all finished. I dimpled the covers for the inspection holes. The aileron push tube slot doublers are installed. I've finished the bottom aileron gap seals both top and bottom. The aileron end caps, and the wing tips are about finished.   I've installed my heated pitot. I started to install my nav lights with strobes and the wing tips are screwed down. I've mounted the PIAA 1500XT landing lights and I fashioned a plexiglass  lens to cover the cut out in the LE. The lower wing root fairings have been started, and the fiberglass root fairings have been fitted. The landing gear wheel assemblies are aligned and installed. Nylon brake lines and compression fittings inside the cabin are finished, ATF fluid inserted and brakes bled and tested successfully.  The parking brake valve is located, but needs the T-handle push pull cable installed. The wheel pants are set to place and the gear leg fairings are partially trimmed and clekoed to position.
The Main  Electrical supply and ground wires are installed from both batteries to the buses. The Blue Sea BatteryLink ACR battery isolatorAlternate/Secondary  Dual Battery System is installed, modified, and working properly. Service wires from the starter and alternator are set with solenoids and B-lead  circuit protection. The Main DualBus , the E-bus and the B-bus are installed.

I formed brackets for the LSE Plasma III dual electronic ignition control units and stacked them into place. I made a bracket for the MAP sensor on top of the LSE controllers and  wired the various engine sensors to the GRT EIS.  I've drilled the firewall and connected 3 bundles of EFIS and Plasma III ignition wires, all are installed and ready to go!

The throttle quadrant, control cables and the cabin fuel lineselectric fuel pump,  high pressure fuel filter, and fuel totalizer. All are adjusted and finished. is installed and works great.The aft baggage shelf and close-out are finished. The new  hat rack , and extended baggage floor are fitted and ready to paint. The static lines are connected and the canopy track nutplates are epoxied in place. The ACK ELT with annunciator has been located, batteries installed and operation tested and confirmed.


I've wired the elevator trim tab servo, the TruTrak Autopilot pitch and roll servos, a tail light on the lower rudder cap.  I have wired my stick grips, and ran the ELT cable to the instrument panel annunciator. The flap motor is wired to the stick grip. The two battery solenoids are located, and the main bus is riveted  to position on the left boot cowl shelf. I've located and riveted the aux (avionics) bus on the right sidewall, opposite the throttle quadrant.

The Instrument Panel is in position and is complete except for paint. I installed a keyed ignition switch in the right sub frame. The nine W51 rockers are installed and tested.  I placed an eyeball vent in the right panel sub frame with a duct to a sidewall NACA duct.  I inserted an old style split master in the panel near the key.  The RadioRax avionics mounting rails are riveted to place and holding the 4 Garmin trays. The fuel pump, landing lights, nav lights, strobe lights, autopilot and heated pitot wiring/switches are completed and working properly.

The Mark III flap mechanism installed and wired to relays in the stick bay. Fabricated rear seat side wall cover panels and arm rests.  The aft inspection panel is finished. I split and re-glassed the empennage fairing and have it screwed to place.

The  RudderElevatorsHS  and the  VS are installed. The rudder stops are set, and the cables are run.  The elevator control tubes are finished. I need to finish the tail light and the end caps. Lots of fiberglass finishing work to do down the road on the tail feathers.

The Canopy slider and SSW are completed. The latch mechanism is installed. The Windshield Faring is glassed and coated with 2 layers of micro. Lots of finishing to do there, but the canopy is essentially complete!

I bought a 3 -bladed MT aerobatic (counterweighted)  Propeller and governor. The MT governor was recalled, repaired and returned by MT to replace an inadequately heat treated part. The prop is installed and needs safetied. Mattituck shipped me the correct longer STUDS for the engine case and the prop governor is installed. After the engine started and stopped, the prop went from low pitch back to high pitch when the oil pressure bled off. FAA Registration: I sent the kit plane Bill of Sale, the FAA original triplicate registration application and a notarized affidavit of ownership in to the FAA, with my $5 check of course!  That was 4/2/07. I got my registration for N540MT back three weeks to the day!!!!  WOOHOO!


Disclaimer: What you will find in the following pages is a more or less chronological history of my F1 EVO Rocket build. I'm working on many different aspects of the airframe at the same time, so updates often occur on multiple pages simultaneously. The pages are arranged by major component, and somewhat follow the plans. BTW, I am not  purporting that I am an expert on how to build ANYTHING, I'm just showing how I did it, right and sometimes wrong. This is my first kit plane project, so please don't  take me or this website as any kind of authority, because I am NOT any sort of kit building or aircraft mechanical authority.





" 49% finished, 90% to go... " - the lament of a kit builder...


Click here to go to Team Rocketevoprototype.jpgI've built a kit airplane. Yep, that's right. And I am flying it too. I've been looking for a plane that will cruise at least 200 mph and go 1000 miles on a tank of gas. Going  FAST and FAR is the whole idea. And the Team Rocket F1 is the machine that fits the bill!

Buying a new or newer certified production aircraft with the same capability, you're talking several hundreds of thousands of dollars. That, I don't have to just throw around on a "hobby" (although it's more a passion).

My goal was to find a single engine airplane that would take me from Central Indiana to Tampa or New Orleans non stop. Well, I found several planes that could do that. But to get one that I could better afford, I chose to build my own. Plus I'll have the advantage of being certified to be a FAA approved mechanic on my own airplane!

The Team Rocket  F1 Rocket can cruise at well over 200 mph. It can fly about 5 hours at lower power settings. As most people will tell you, about 3 or 4 hours in a small plane is about most of us private pilots can manage. I think I'm good for 4+, especially if I know I can get there in one hop. The back and the bladder are the deciding factors on stops, more so than fuel.


If you get up around 10,000 feet, you can get around 230 to 240 mph. Maybe even more!  But you won't fly 4 hours at full throttle down low. With 52 gallons total, and the Lycoming IO-540 burning 16 gph or a lot more, 3 hours of wide open fun is all you'll probably get.

Another consideration is that the F1 is also fully aerobatic. It handles about the same stresses as my Super Decathlon, rated at +6 and -3 g's. And like the SD, it's tandem seating, so you and the controls are centered in the ship. That makes maneuvers easier and much more fun!

My quick build F1 EVO  kit arrived to my home May 10, 2004 in very good shape. I used Team Rocket's recommended ABF trucking, which TR set up. Cost about $1100 to have the kit trucked to my door. The kit was hand packed in the back of a 'pup' trailer, and enclosed/blocked off by itself. TR loaded the truck by hand for no charge and no crating fees. That's good, because crating a 17 foot fuselage and an 15 or so foot pair of taper wings would cost a small fortune.
The quality of the quick build parts appears very nice. They were pretty well packed and organized, and most parts are labeled. The only (minor) problem is that some of the parts are marked with indelible ink and I can't get some of them cleaned off, and paint won't hide it. Some parts aren't marked, but it's not hard to figure out what the are. Much of the parts comes primed already! That was a pleasant surprise. It looks like they are using "MarHyde" type primer. It comes off with lacquer thinner, but not very easily. Very durable stuff.


One big note about this quick build kit: Although the parts are very
well engineered and beautifully constructed, you do have to build this thing. It is not merely an assembly process like an erector set. Only a few parts are pre-punched, so there's a ton of measuring, marking, and making decisions where to drill, rivet and assemble. There's just a lot more work to constructing this kit than you might find with a brand "V" pre punched quick build kit plane.  Most Team Rocket parts go together beautifully, and typically only one way, so it's hard to screw it up. It certainly could be much harder than it is, because the F1 is indeed a quick build kit, with much of the most complicated work done for you at the factory. The EVO wings and control surfaces come quite complete. The fuselage comes like a big canoe with all the bulkheads in place. Even the stainless firewall is in place. Very nice!





Having worked on this plane many months, I can tell you it was a lot of fun !  The work progressed nicely, and there were many gratifying moments of accomplishment. Team Rocket (Mark Frederick) is very helpful, and this kit is just COOL! Most of my problems and frustrations in building came from my lack of construction experience and  building skills.  This kit is not all that difficult to construct. It's just frustrating and puzzling at times. But as each component comes together you get a MAJOR sense of accomplishment and satisfaction.

My goal was to get a safe, well constructed plane put together and go fly. I didn't try for a show winner. I don't have the skills (yet) or the patience (never). I'm not going to languish over minor cosmetics or complexity.  I did the best I could, and I got much better as the project progressed. But I sure try not to sweat the small stuff. You do that too much, and you'll never get finished. Remember, my goal was to FLY the darn thing. I like the building experience, but the means were mostly to justify the end! And now having flown my Rocket, it certainly was worth the effort.


     The EVO wing took a long tim to get into production. Flight testing showed that the plane may not have the 6% more top speed (yet!), but the stall speed has been lowered to 42 knots! The landing speed is now supposed to be noticeably slower than any RV, in part perhaps due to the semi-Fowler type flaps as well as the tapered wing. In fact, many have said that the F1 EVO lands as easy and slow as a Cessna 150! Not bad for a 250 mph airplane!  Having flown my EVO and landed many times, I can tell you that flying and landing this plane is easier than my Super Decathalon, and slower than my 7KCAB Citabria.  For a tail dragger, it couldn't be much easier to wheel land. 3 points are just as sweet, but you have to be prepared to land somewhat blind because you can't see over the nose. That just takes getting used to, it's more of a head game than actually difficult or dangerous. Think of all those big radial WWII era airplanes that have been landed that way for decades. Piece O Cake.




Below is Team Rocket's "Ole' 84", which I call the "factory ship" (now owned by Doug Rozendaal in Mason City, IA). This was taken at Sun And Fun 2004.


Vince Frazier has a gorgeous F1H. Yep, that's a Team Rocket/Harmon Rocket hybrid. Best of both worlds?  Well, it's awesome. And one Saturday he gave me a taste. He let me sit in it!  Of course he took the keys out.   HAH! Later he actually let me fly it from the rear seat. SWEET! Notice in the pic below that he chose to make a tip-over canopy instead of the standard slider. That's just a matter of preference.
I think the front half of Vince's plane is Team Rocket, and the back end of the plane is Harmon Rocket. But I'm not sure. If you are interested, there is a link to his massive and informative website, or just click the pic. I may not remember the particulars, but I do know that this is ONE FINE ROCKET!  You might not be able to tell the sheen in the pics, but this is one of the shiniest and prettiest paint jobs I have seen. The lower is a clear coated silver metallic that is just beautifully finished. I think Vince said that his paint was PPG.  Man, does it look terrific! Well Done Vince!


Click Here to go to Vince's Website!

Randy Pflanzer has a gorgeous F1 Rocket (pictured below). His website, Pflanzer-Aviation.com, has been the largest source of building information, next to the TR construction manual, for my project. If you are building a Rocket, you need to visit his website.


Randy Pflanzer's F1 Rocket



Greg Nelson flew his exquisite F1 Rocket from California to Sun and Fun 2004. His plane is immaculate! I spent a few hours around his Rocket listening to his explanations and going over his plane. What a beauty!


Do you think these F1's have some get up and GO?  You BETCHA!  Just let Greg Nelson show you how:

Greg Nelson Goes VERTICAL!


I've visited Jim Wining's shop a few times and learned quite a lot during his F1 Rocket build. His yellow #34, has over 150 hours in the air! Congratulations, Jim! And thanks for the ride! Nothing like a loop and a roll in a Rocket to keep you motivated!  What a smooth, quiet ride!

Jim Wining's F1 Rocket


I took my FIRST  F1 Rocket ride with Jim Winings, who had just flown off the minimum time on his ship. Jim is an excellent pilot and the plane was nothing short of PHENOMENAL. Let me tell you that I was impressed at how smooth, quiet, responsive, powerful, comfortable, and docile the F1 Rocket is in the air and on the ground. IMPRESSIVE!!! Yes, I took a big leap of faith buying this kit, never having flown in one (let alone taking the controls).  Not that I didn't try to get a demo flight. Mark just never could accommodate me. Doesn't matter. If my plane flies anything like Jim's (it does), I'll have it made (I do!). It's going to be a little bit of apples versus oranges, because Jim has made quite a few mods to his plane. Many of those mods should be standard on the kit, in my opinion. None the less, the airframes are essentially the same, except that I'm putting on the EVO wings.

Not only was that my first Rocket ride, that was my first EXPERIMENTAL ride of any kind. Never even been in an RV!  How's that for confidence in Mark's F1 Kit?!  I'm telling you, the handling was superb. The visibility in Jim's plane will be better than mine. You might notice he has the tip over canopy. That thing is beautiful. Talk about visibility! It was like an open cockpit without the wind or noise. None.  And EASY to get in and out (relatively).


Here's another great looking F1 Rocket. Bill Tew is out there on the right side of the US. His Rocket boasts a KTM custom IO-540 and he reports it to be as smooth as silk!

Bill Tew's N5491W.jpg

Eric Hansen has a beautiful F1 up in Canada. Fresh out of the paint shop 4/05, just in time for Spring.


Yet another new F1 Rocket from Canada, below is Mark Esterhuizen's kit #85, complete with TACS (Taxi Aid Camera System). Yes, the nose is a little high on these birds, and unless you have a forward looking camera  (or periscope) on the ground, S turns while taxiing are mandatory.




DO NOT do business with Michael H. Moore of AvWorks Inc.,  in Mooresville, North Carolina.  That cheating liar still owes me a LOT of money. Read HERE.
